MAX Trailer MAX100
Please note that the vehicle shown may differ from the actual offer in terms of colour and accessories. For further information, please contact us.
- Chassis number 112137
- Reference MAX100-N-3A-9.30-FTR
- Number of axles 3
- Condition New
- Year of manufacture 2026
- Colour Colour selectable
- Availability 08/2026
- Steering Type Friction
The most important documents
Detailed information
Technical data
Weights
| Technical value 80 km/h | |
|---|---|
| Tare weight +- 3% | 10023 kg |
| Payload | 39477 kg |
| King pin load | 18000 kg |
| Axle load | 31500 kg |
| Gross weight | 49500 kg |
Dimensions
| Fifth wheel height loaded | 1250 mm |
| Gooseneck length | 3 850 mm |
| Turning circle reversing | 2 300 mm |
| Loading platform length | 9 300 mm |
| Extendable by | 4 100 mm |
| Wheelbase | 1 360 mm |
| Loading height at max. load | 860 mm |
| Total width | 2 540 mm |
| Suspension stroke | -55/ +145 mm |
Gooseneck
1 x Gooseneck : MAX-3.850-750-10° (DSR 2300/ASH 1250) 45°
Gooseneck with chamfered corners ± 45° in front and rear chamfered by ± 750 mm x 10°.
3 pairs of lashing rings (LC 5 000 daN).
Hardwood cover thickness 30 mm.
- One spare wheel with holder on the headboard.
- King pin 2
- One galvanised steel headboard, height ± 400 mm.
- Red and yellow air couplings on the galvanised front connection ledge.
- 2 wheel chocks with carrier on the headboard.
-
On the gooseneck removable sideboards and rearboard in alu ca. 2 400 x 400 mm (L x H).
The galvanised rear stakes are dismountable.
(Length of the structure ca. 2 560 mm) (± 46kg). - 1 galvanized toolbox integrated in the charmfered gooseneck (± 47 kg).
Loading deck
Loading platform
1 x Loading platform : MAX100-N-3A-9.30-17.5-2.54-FTR{HB-GR}
Loading platform in extendable version.
6 pairs of lashing rings in the loading platform, hinged outwards (LC 5 000 daN).
3 pairs of lashing rings in the loading platform, hinged outwards (LC 10 000 daN).
1 pair of lashing rings in front in the firm part the loading platform (LC 10 000 daN).
Cutouts in the border frame of the loading area for hooking in tension belts (LC 2 000 daN).
Hardwood cover thickness 48 mm, above the axles chequer plate.
- On the right and left on the gooseneck and at the rear of the trailer one holder for the warning boards with socket.
- Holder for one beacon light at the rear of the trailer.
- Profile displaceable as hook-on device for alu-ramps at the rear.
- Cable control for the hydraulic rear.
- Yellow reflective tape according to the EU regulation over the entire length, on the extension and at the rear.
- Electrically operated hydraulic pump at the rear under the loading platform. (± 45 kg)
- Reflectors (red - yellow) according to the EU regulation at the rear of the trailer.
- 4 pairs of WADER containerpockets in the loading platform for 1 x 20', 1 x 30' or 1 x 40' containers. (± 40 kg)
- 6 pairs of pockets for stakes ca. 100 x 50 mm in the outer frame of the loading platform (± 18kg).
- Galvanised outriggers, extendable up to ± 230 mm per side (± 262 kg).
- Galvanised storage across under the loading platform. (± 150kg)
- 1st Lift axle on the front axle with control by TEBS-E depending on the current axle load (± 69kg)
- A tool box INOX 565x290x810 in the direction of travel right in front of the axles (± 45 kg)
- 2 LED- reversing lights at the rear.
- Load manometer for determining the axle load, including load diagram.
Ramps
Hydraulic loading ramps
1 x FTR : FTR-HB
Loading area at the rear with hardwood cover can be lowered hydraulically over a length of ± 2 125 mm.
Load capacity of the rear section raised: 6 000 kg.
The rear of the vehicle can be driven on with an axle load of 12 tonnes.
-
1 pair of alu ramps VFR 120 ± 1 500 x 450 mm (l x w)
Capacity per ramp for :
Bogie 2 axles with load distribution 40% to 60%
by axle distance 1.5 meter : 15 000 daN (Kp)
by axle distance 2.0 meter : 15 000 daN (Kp)
single axle: 9 010 daN (Kp)
max. admissible uphill : 21.7°
Weight per ramp ± 39 kg (± 78 kg) - Holder for alu-ramps,under the ramp. (± 88kg)
Accessories
1 x Accessory
MAX100-Accessory
- Cable for the the electric-hydraulic pump and/or electric winch (35 mm², 3.5 m length, max. 160 A) between the semi-trailer and the truck with socket (ANDERSON-ANDERSON).
- Manual and description on USB stick .
- Holder for a 2nd numberplate at the rear end included a lighting.
- Delivery from a trailer to factory Lentzweiler.
Request vehicle
We look forward to receiving your enquiry. We will respond as quickly as possible.
- Chassis number 112137
- Reference MAX100-N-3A-9.30-FTR
- Number of axles 3
- Condition New
- Year of manufacture 2026
- Colour Colour selectable
- Availability 08/2026
- Price On request
-
