Cometto Eco500
Please note that the vehicle shown may differ from the actual offer in terms of colour and accessories. For further information, please contact us.
- Chassis number TBD offer 96-250124101739
- Reference Eco502/2 D Long
- Number of axles 0
- Condition Used
- Colour Colour selectable
- Availability Directly available
Detailed information
Bogie
Self-propelled bogies
1 x Modul Eco502/2D Long
2-axle lines Long Heavy-Duty Platform Unit equipped with 2 self-driven axles and all-wheel electronic-hydraulic steering .
Platform 2.350 mm wide, for loads up to 38 t per axle line and high concentrated loads.
On the platform it is possible to install a Diesel PPU
Specification taken from technical description Eco500
- Wheels: RAL 9005 black
- High Resistance Metalisation (HRM) of the complete steelconstruction, after all welding works the structure is shotblasted and a layer of zinc (85%) - aluminium (15%) is applied.
- Kit of 4 quick couplings and pipes to allow the interconnection of suspensions between Eco500 modules.
- Platform width: 2.350 mm
- Type of suspension: pendular
- Platform with anti-slip sand-coating.
-
8x Solid tyres
Non-marking -
Electronic leveling system, including the inclinometer sensors and software.
(available only with the equal lift system installed)
The system work with the equal lift system and allow to keep the horizontal position of the platform when ground is uneven. -
Equal lift system Including 8 ultrasonic sensors for height measuring (2 per each corner) and the equal / parallel electronic and software.
The system allow to lift the suspensions with the same speed in parallel mode. -
Working led lights for module.
8 led lights in total, 2 lights installed per side and 2+2 on the heads.
Painting
| Outer frame | N/A - RAL-nbr.: .................... (please confirm) |
| Chassis | RAL 7021 - Black grey |
Powerpack
PPU Accessoires
1 x Eco500 Compact remote control
Compact radio remote control.
It allows to handle the vehicle from a distance up to 50 m.
Remote control for all functions of vehicle with a display showing main data of convoy.
Receiver to be connected to Eco500 module
Small size
Frequency: 2,4 GHz
Supplied with 2 batteries, a 12V charger, and a cable for work without radio comunication.
Charger directly connectable to powerpack.
Accessories
General accessories
1 x Eco500 Tools kit: Essential
Kit of tools for general operations and basic maintenance on a Eco500 single trailer.
Request vehicle
We look forward to receiving your enquiry. We will respond as quickly as possible.
- Chassis number TBD offer 96-250124101739
- Reference Eco502/2 D Long
- Number of axles 0
- Condition Used
- Colour Colour selectable
- Availability Directly available
- Price On request
-
